SKU
61-254525-1
Alt #:
117093
Chevy Truck Wiring Diagram, 1967
0
Reviews
Add Your Review
$7.99
Each
Product Details
This is another one of those "must have" books for your Chevy or GMC truck library. 1967 Chevrolet and GMC truck wiring can be a really spooky thing to the beginning restorer. We have had many calls on the technical assistance lines where someone has turned their truck's wiring into a pile of recyclable copper because they did not know exactly where a certain wire went. End the mystery today by purchasing this inexpensive wiring diagram from Eckler's Classic Chevy Trucks.
Availability:
Ships Direct from Manufacturer - 2-3 Week Delivery
- Full Wiring Schematic
- Wire Sizes
- Fuse Placement and Values
This is another one of those "must have" books for your Chevy or GMC truck library. 1967 Chevrolet and GMC truck wiring can be a really spooky thing to the beginning restorer. We have had many calls on the technical assistance lines where someone has turned their truck's wiring into a pile of recyclable copper because they did not know exactly where a certain wire went. End the mystery today by purchasing this inexpensive wiring diagram from Eckler's Classic Chevy Trucks.
1967 Truck Wiring Diagram
| Base Part Number | 254525 |
|---|---|
| Alt. # | 117093 |
| Eck OEM Number | 67-WDT |
| Brand | N/A |
| Make / Model | Series | Body | Notes | Year |
|---|---|---|---|---|
| Make / Model Chevrolet | Series | Body | Notes | Year 1967 |
| Make / Model Chevrolet Truck | Series | Body | Notes | Year 1967 |
